汽車MOS 通用MOS

Model No. 型號(hào)	Package Type 封裝形式	Config AP ration 配置比例	MOSFET Type MOS類型	VDS(V) DS耐壓	VGS(V) GS耐壓	Vth(V) Vth(V)	RDS(ON)(mΩ)max. at VGS= RDS(ON)(mΩ)max. at VGS=		ID(A) ID(A)
Model No. 型號(hào)	Package Type 封裝形式	Config AP ration 配置比例	MOSFET Type MOS類型	VDS(V) DS耐壓	VGS(V) GS耐壓	Vth(V) Vth(V)	10V	4.5V	Tc=25℃	TC=100℃
AP2300B	SOT23	Single	N	20	±10	0.5~1.2		23/26	5.2	4
AP130N100D	TO-263	Single	N	100	20/-12	2~4	5/5.5		130
AP2316	SOT23	Single	N	30	±12	0.7-1.4	31/40	35/46	4.2	-
AP8205F	SOT23-6	DAPal	N+N	20	±8	0.5~1.2		15/18	8	6.2
AP045N03Q	DFN3X3	Single	N	30	±20	1~2.5	4.8/5.5	8/10	75
AP0603Q	DFN3X3	Single	N	30	±20	1~2	5.5/6.5	9.5/11	40	30
AP120N03K	TO-252	Single	N	30	±20	1~2.5	4.8/5.5	8/10	90	65
AP150N03	TO-220	Single	N	30	±20	1~2.5	3.1/3.5	4.3/5	150
AP150N03K	TO-252	Single	N	30	±20	1~2.5	3.1/3.5	4.3/5	120	-
AP30H100K	TO-252	Single	N	30	±20	1~2.5	4.8/5.5	8/10	90	65
AP3400S	SOT23-3	Single	N	30	±12	0.7~1.4	17/21	20/25	5.8
AP83T03K	TO-252	Single	N	30	±20	1~2.5	5.6/6.5	9/12	75	53
AP23N06K	TO-252	Single	N	60	±20	1.2~2.5	30/35	33/40	20	-
AP30N06K	TO-252	Single	N	60	±20	1~3	26/30		30	17
AP4946	S0P8	DAPal	N+N	60	±20	1.2~2.5	33/45	36/52	5
AP60N06	TO-220	Single	N	60	±20	1.2~2.5	15/17	19/21	50
AP1003S	SOT23-3	Single	N	100	±20	1~3	110/135	115/140	3
AP10N10K	TO-252	Single	N	100	±20	1~2	100/115	110/135	10	62
AP10N10S	SOP-8	Single	N	100	20/-12	1-2.5	12/14	18/21	10
AP130N100	TO-220	Single	N	100	20/-12	2~4	5/5.5		130
AP50N100K	TO-252	Single	N	100	20/-12	1~2.5	11/13	17/20	50
AP59N10	TO-220	Single	N	100	20/-12	1~2.5	11/13	17/20	59	-
AP59N100	TO-220	Single	N	100	20/-12	1~2.5	11/13	17/20	59
AP70N100K	TO-252	Single	N	100	20/-12	1~2.5	7/9	10/12	70
AP060N70	TO-220	Single	N	70	20/-12	2~4	5.9/6.5		90
AP80N100	TO-220	Single	N	100	20/-12	1~2.5	7/9	10/12	80
AP130N55	TO-220	Single	N	55	20/-12	2~4	3.9/4.5	-	130
AP130N55D	TO-263	Single	N	55	20/-12	2~4	3.9/4.5	-	130
AP1310(K)	TO-252		N	100	20/-12	1~2.5	11	15	55	-
AP2302	SOT23	Single	N	20	±10	0.5~1.2		30/40	4	-
AP30P10	TO-251/TO-252	Single	P	-100	±20	1.3-2.5	32/38	36/45	35	25
AP40N100KA	TO-252	Single	N	100	±20		18		45	36
AP2302B	SOT23	Single	N	20	±8	0.5-1.2	-	45/52	2	-
AP2300	SOT23	Single	N	20	±10	0.3-1	-	25/31	5.2	4
AP2312	SOT23	Single	N	20	±8	0.45-1	-	18/23	6	4.8
AP3416	SOT23	Single	N	20	±10	0.5-0.9	-	13/15	6.8
AP3402	SOT23	Single	N	30	±12	0.7-1.4	31/40	35/46	4.2	-
AP3400	SOT23	Single	N	30	±12	0.7-1.4	17/21	20/25	5.8	-
AP3404	SOT23	Single	N	30	±20	1-2.5	18/22	23/30	6.5	-
AP2N7002	SOT23	Single	N	60	±20	0.7-2	1300/2000	1500/2000	0.45	-
AP2310	SOT23	Single	N	60	±20	0.8-1.4	75/90	85/120	3	-
AP1002	SOT23	Single	N	100	±20	0.8-2.0	210/273	260/338	2	-
AP2301B	SOT23	Single	P	-20	±12	0.5-1.2	-	120/150	2	-
AP2301	SOT23	Single	P	-20	±12	0.5-1.2	-	66/80	3	-
AP2305	SOT23	Single	P	-20	±12	0.5-1	-	40/50	4.1	-
AP2333	SOT23	Single	P	-20	±12	0.5-1	-	25/30	5	-
AP2317	SOT23	Single	P	-20	±12			18/22	6	-
AP3415E	SOT23	Single	P	-20	±12	0.7-1.2	33/38	52/60	4	-
AP3401	SOT23	Single	P	-30	±12	0.7-1.2	47/55	55/70	4.2	-
AP3407	SOT23	Single	P	-30	±20	1-2.5	54/70	80/95	4.1	-
AP40P05	SOT23	Single	P	-40	±20	1-2.5	65/85	85/120	5	-
AP2318A	SOT23-3	Single	N	20	±8	0.5-1.2	-	10/12	6	4.8
AP3400A	SOT23-3	Single	N	30	±12	0.7-1.4	17/21	20/25	5.8	-
AP3404S	SOT23-3	Single	N	30	±20	1-2.5	18/22	23/30	6.5	-
AP3100A	SOT23-3	Single	N	30	±20	1-2.5	10/12	13/17	9
AP2310S	SOT23-3	Single	N	60	±20	0.8-1.4	75/90	85/120	3	-
AP5N10S	SOT23-3	Single	N	100	±20	1-3	110/135	115/140	3	-
AP2335	SOT23-3	Single	P	-20	±12	0.5-1	-	19/25	7	-
AP2317A	SOT23-3	Single	P	-20	±12			18/22	7	-
AP3401S	SOT23-3	Single	P	-30	±12	0.7-1.2	47/55	55/70	4.2	-
AP3407S	SOT23-3	Single	P	-30	±20	1-2.5	54/70	80/95	4.1	-
AP4P20	SOT23-6	Single	P	-20	±12	0.5-1	-	40/50	5	-
AP8205	SOT23-6	Dual	N+N	20	±8	0.5-1.2	-	19/24	6	4.8
AP6802	SOT23-6	Dual	N+N	30	±20	1-2.5	31/40	46/60	4	-
AP6800	SOT23-6	Dual	N+N	30	±12	0.7-1.4	20/24	23/27	5	-
AP2003	SOT23-6	Dual	N+P	-20	±12	0.5-1.2	-	23/66	3	-
AP3003	SOT23-6	Dual	N+P	-30	±12	0.7-1.2	20/50	24/65	4.2	-
AP6900	SOT23-6	Dual	N+N	40	±20	1-2.5	30/36	40/48	4
AP8205A	TSSOP-8	Dual	N+N	20	±8	0.5-1.2	-	23/28	6	4.8
AP8810	TSSOP-8	Dual	N+N	20	±12	0.45-1	16/20	19/24	7	5.2
AP2012	TSSOP-8	Dual	N+N	20	±12	0.7-1	-	9/13	12	-
AP2012S	SOP-8	Single	N	20	±12	0.7-1	-	9/13	12	-
AP3010	SOP-8	Single	N	30	±20	1-2.5	10/13	13/18	10	6
AP4410	SOP-8	Single	N	30	±20	1-2.5	6.5/8	10.2/13	15	10
AP3004S	SOP-8	Single	N	30	±20	1-2.5	5/6	7/9	20	14
AP4013S	SOP-8	Single	N	40	±20	1-2.5	17/22	22/30	10	6.5
AP6009S	SOP-8	Single	N	60	±20	1-2.5	14/18	17/21	9
AP6007S	SOP-8	Single	N	60	±20	1-2.5	9.5/12	12/17	12
AP9435	SOP-8	Single	P	-30	±20	1-3	50/58	65/80	5.3
AP4435C	SOP-8	Single	P	-30	±20	1-3	16/20	27/35	10.5	-
AP4407	SOP-8	Single	P	-30	±20	1-3	10/14	15/19	12	-
AP4407C	SOP-8	Single	P	-30	±20	1-3	10.5/14	15/19	12	-
AP20P30S	SOP-8	Single	P	-30	±20	0.8-2	8.5/12	11/13	15	-
AP4409S	SOP-8	Single	P	-40	±20	1-2.5	12/14	17.5/20	15	-
AP30P30S	SOP-8	Single	P	-30	±20	1-2.5	12/14	17.5/20	12	-
AP9926	SOP-8	Dual	N+N	20	±10	0.5-1.2	-	21/26	6.5	-
AP2022S	SOP-8	Dual	N+N	20	±12	0.7-1	-	9/13	15	-
AP4812	SOP-8	Dual	N+N	30	±20	1-2.5	18/22	23/30	8	-
AP3020	SOP-8	Dual	N+N	30	±20	1-2	12/15	15/20	10	6
AP4008SD	SOP-8	Dual	N+N	40	±20	1-2.5	17/22	22/30	10	6.5
AP4946S	SOP-8	Dual	N+N	60	±20	1.2-2.5	28/35	34/42	5	-
AP4847	SOP-8	Dual	N+N	60	±20	1.2-2.5	17/21	22/28	7	-
AP4846	SOP-8	Dual	N+N	60	±20	1.2-2.5	15/18	20/24	7	-
AP4953B	SOP-8	Dual	P+P	-20	±12	0.7-1.2	-	66/80	3	-
AP2317SD	SOP-8	Dual	P+P	-20	±12	0.3/0.65/1.0		18/22	18
AP4953	SOP-8	Dual	P+P	-30	±20	1-2.5	53/60	80/95	4.1	-
AP2714QD	PDFN3X3-D	Dual	N+P	40	±20	1-2.5	17/22	22/30	16
AP2714QD	PDFN3X3-D	Dual	N+P	-40	±20	1-2.5	27/35	48/60	18
AP2714SD	SOP-8	Dual	N+P	40	±20	1-2.5	17/22	22/30	10	6.5
AP2714SD	SOP-8	Dual	N+P	-40	±20	1-2.5	27/35	48/60	12	-6.5
AP2716QD	PDFN3X3-D	Dual	N+P	40	±20	1-2.5	17/22	22/30	16
AP2716QD	PDFN3X3-D	Dual	N+P	-40	±20	1-2.5	35/44	35/50	16
AP4616	SOP-8	Dual	N+P	-30	±20	1.2-2.5	10/18	15/25	10	7.8
AP2716SD	SOP-8	Dual	N+P	40	±20	1-2.5	17/22	22/30	10	6.5
AP2716SD	SOP-8	Dual	N+P	-40	±20	1-2.5	35/44	35/50	10	-6.5
AP3065SD	SOP-8	Dual	N+P	40	±20	1-2.5	30/40	42/60	7
AP3065SD	SOP-8	Dual	N+P	-40	±20	1-2.5	65/85	90/120	6
AP3908GD	PDFN5X6-D	Dual	N+P	30	±20	1-3	9.5/14	11/20	36
AP3908GD	PDFN5X6-D	Dual	N+P	-30	±20	1-2.2	16/23	25/34	25
AP3908QD	PDFN3X3-D	Dual	N+P	30	±20	1-3	9.5/14	11/20	20
AP3908QD	PDFN3X3-D	Dual	N+P	-30	±20	1-2.2	16/23	25/34	20
AP4438	SOT-89	Single	N	30	±20	1-2	10/13	13/18	10	6
AP1606	DFN1006	Single	N	20	±8	0.5-1.2	-	180/220	0.7	-
AP1605	DFN1006	Single	P	-20	±8	0.45-1	-	360/420	0.7	-
AP6242	DFN2*2	Single	N	20	±12	0.5-1	-	9/13	12	-
AP2080Q	PDFN3X3	Single	N	20	±12	0.5-1	-	9/11	30	-
AP2045Q	PDFN3X3	Single	N	20	±12	0.5-1	-	4.8/5.5	60	-
AP2035Q	PDFN3X3	Single	N	20	±12	0.5-1	-	3.1/4	70	-
AP0903Q	PDFN3X3	Single	N	30	±20	1-2	8.5/10.5	11/14	16	10
AP30H50Q	PDFN3X3	Single	N	30	±20	1-2.5	6.5/9	9.0/14	40	-
AP30H80Q	PDFN3X3	Single	N	30	±20	1-2.5	4.8/6	7.5/12	70	-
AP90N03Q	PDFN3X3	Single	N	30	±20	1-2.5	3.6/4.2	5/7	80	-
AP30H150Q	PDFN3X3	Single	N	30	±20	1-2.5	3.1/3.5	4.3/5	100	-
AP150N03Q	PDFN3X3	Single	N	30	±20	1-2.5	2.4/3.2	4.5/6.2	120	95
AP50N04Q	PDFN3X3	Single	N	40	±20	1-2.5	10/13	13/20	20	14
AP60N04Q	PDFN3X3	Single	N	40	±20	1-2.5	7.4/9.3	10.4/14.3	30
AP80N04Q	PDFN3X3	Single	N	40	±20	1-2.5	5.7/7.5	9/11	40	27
AP85N04Q	PDFN3X3	Single	N	40	±20	1-2.5	5.0/5.9	7.5/10	50
AP90N04Q	PDFN3X3	Single	N	40	±20	1-2.5	4.2/5.5	6.5/7.5	60
AP50P20Q	PDFN3X3	Single	P	-20	±12	0.3/0.65/1.0		6.6/8.5	50	32
AP60P20Q	PDFN3X3	Single	P	-20	±12	0.3/0.65/1.0		5.8/7	60	42
AP15P03Q	PDFN3X3	Single	P	-30	±20	1-3	15/20	25/35	10.5	-
AP18P30Q	PDFN3X3	Single	P	-30	±20	1-2.5	10.5/14	15.5/19	20	-
AP20P30Q	PDFN3X3	Single	P	-30	±20	1-2.5	9/11	12/15	20	-
AP25P30Q	PDFN3X3	Single	P	-30	±20	1-2.5	8.5/11	12/15	25	-
AP30P30Q	PDFN3X3	Single	P	-30	±20	1-2.5	7/10	10/13	30	-
AP90P03Q	PDFN3X3	Single	P	-30	±20	1-2.5	5.8/7.5	9/12	60	42
AP2317QD	PDFN3X3-D	Dual	P+P	-20	±12	0.3/0.65/1.0		18/22	18
AP4822QD	PDFN3X3-D	Dual	N+N	30	±20	1-2.5	16/22	21/30	8	-
AP0803QD	PDFN3X3-D	Dual	N+N	30	±20	1-2	8.5/10.5	11/14	10	6
AP3910GD	PDFN5X6-D	Dual	N+P	30	±20	1-2.5	9.5/14	11/20	36
AP3910GD	PDFN5X6-D	Dual	N+P	-30	±20	1-2.2	11/14	15.5/20	30
AP4008QD	PDFN3X3-D	Dual	N+N	40	±20	1-2.5	17/22	22/30	20	13
AP50N04QD	PDFN3X3-D	Dual	N+N	40	±20	1-2.5	13/15	17/20	20
AP3912GD	PDFN5X6-D	Dual	N+P	30	±20	1-2.5	10/13	14/19	36
AP3912GD	PDFN5X6-D	Dual	N+P	-30	±20	1-2.2	12/15	18/20	28
AP4606	SOP-8	Dual	N+P	30	±20	1-2.5	18/25	25/38	7	-
AP4606	SOP-8	Dual	N+P	-30	±20	1-2.5	28/35	44/58	6	-
AP2080G	PDFN5X6	Single	N	20	±12	0.7-1	-	9/11	40	-
AP2045G	PDFN5X6	Single	N	20	±12	0.7-1	-	4.2/4.8	60	-
AP2035G	PDFN5X6	Single	N	20	±12	0.5-1	-	3.1/4	70	-
AP2020G	PDFN5X6	Single	N	20	±12	0.7-1	-	2.9/3.5	90	-
AP0903G	PDFN5X6	Single	N	30	±20	1-2	8.5/10.5	11/14	25	15
AP30H80G	PDFN5X6	Single	N	30	±20	1-2.5	4.8/6	7.5/12	70	-
AP040N03G	PDFN5X6	Single	N	30	±20	1-2.5	3.6/4.2	5/7	80	-
AP30H150G	PDFN5X6	Single	N	30	±20	1-2.5	3.1/3.5	4.3/5	120	-
AP150N03G	PDFN5X6	Single	N	30	±20	1-2.5	2.4/3.2	4.5/6.2	150	-
AP180N03G	PDFN5X6	Single	N	30	±20	1-2.5	1.7/2.1	3.2/4	180
AP30H220G	PDFN5X6	Single	N	30	±20	1-2.5	1.4/1.8	2.3/3.2	150	-
AP60N04G	PDFN5X6	Single	N	40	±20	1-2.5	7.4/9.3	10.4/14.3	40
AP80N04G	AP4606B	Single	N	40	±20	1-2.5	5.7/7.5	9/11	50	27
AP85N04G	AP4606B	Single	N	40	±20	1-2.5	5.0/5.9	7.5/10	65
AP90N04G	AP4606B	Single	N	40	±20	1-2.5	4.2/5.5	6.5/7.5	80
AP68N06G	AP4606B	Single	N	60	±20	1.2-2.5	14/16	18/20	50
AP0903GD	PDFN5X6-D	Dual	N	30	±20	1-2.5	8.5/10.5	11/14	16
AP90N03GD	PDFN5X6-D	Dual	N	30	±20	1-2.5	5.2/5.8	8.5/9.5	80
AP90P03G	AP4606B	Single	P	-30	±20	1-2.4	6.3/7.5	10/12	90
AP40P04G	AP4606B	Single	P	-40	±20	1-2.5	10/13	15/22	40	26
AP30P06G	AP4606B	Single	P	-60	±20	1-2.5	26/32	30/43	30
AP4606B	SOP-8	Dual	N+P	30	±20	1-2.5	18/25	25/38	7	-
AP4606B	SOP-8	Dual	N+P	-30	±20	1-2.5	38/50	53/70	5.1	-
AP4606C	SOP-8	Dual	N+P	20	±20	0.7-1.2		25/31	5.2	-
AP4606C	SOP-8	Dual	N+P	-20	±20	0.7-1.2		66/80	3	-
AP4688S	SOP-8	Dual	N+P	60	±20	1.2-2.5	31/50	39/60	8
AP4688S	SOP-8	Dual	N+P	-60	±20	1.0-2.5	52/65	65/75	6
AP4813K	TO-252	Dual	N+P	30	±20	1.0-2.5	20/24	31.5/36	18
AP4813K	TO-252	Dual	N+P	-30	±20	1.0-2.5	54/60	75/85	13
AP2080K	TO-252	Single	N	20	±12	0.7-1	-	9/11	50	-
AP2055K	TO-252	Single	N	20	±12	0.7-1	-	4.8/5.5	60	-
AP2045K	TO-252	Single	N	20	±12	0.7-1	-	4.2/4.8	80	-
AP2020K	TO-252	Single	N	20	±12	0.7-1	-	2.9/3.5	90	-
AP30N03K	TO-252	Single	N	30	±20	1-2.5	16/20	21/26	20	-
AP55N03K	TO-252	Single	N	30	±20	1-2	9.6/12	12/15	30	22
AP30H60K	TO-252	Single	N	60	±20	1-2	6/7.5	9.5/13	50	33
AP30H80K	TO-252	Single	N	60	±20	1-2.5	4.8/5.5	8/10	80
AP30H100KA	TO-252	Single	N	60	±20	1-2.5	3.6/4.2	5/7	100	-
AP30H150K	TO-252	Single	N	60	±20	1-2.5	3.1/3.5	4.9/6	120	-
AP30H150KA	TO-252	Single	N	60	±20	1-2.5	2.4/3.0	4.2/6	120	-
AP30H180K	TO-252	Single	N	60	±20	1.2-2.5	1.9/2.6	2.5/3.4	150
AP30N04K	TO-252	Single	N	40	±20	1.2-2.5	17/22	22/30	30	-
AP50N04K	TO-252	Single	N	40	±20	1.2-2.5	10.5/13	13.5/20	40	31.6
AP75N04K	TO-252	Single	N	40	±20	1-2.5	5.7/7.5	9/11	50	27
AP85N04K	TO-252	Single	N	40	±20	1-2.5	5.0/5.9	7.5/10	65
AP90N04K	TO-252	Single	N	40	±20	1.2-2.5	4.2/5.5	5.3/7	80	50
AP120N04K	TO-252	Single	N	40	±20	1.0-2.5	3.3/4/2	5.4/7.5	120	78
AP25N06K	TO-252	Single	N	60	±20	1.2-2.5	26/35	33/40	20	-
AP40N06K	TO-252	Single	N	60	±20	1.2-2.5	14.5/18	18/22	40	-
AP50N06K	TO-252	Single	N	60	±20	1.2-2.5	13/16	15/18	50	-
AP15N10K	TO-252	Single	N	100	±20	1-3	85/100	90/110	15	-
AP4910GD	PDFN5X6-D	Dual	N+P	40	±20	1-2.5	14/16	20/25	30
AP9N20K	TO-252	Single	N	200	±20	1-2.5	250/300		9
AP2N65K	TO-252	Single	N	650	±30	2-4	4500/5000		2
AP50P20K	TO-252	Single	p	-20	±12	0.35-1	-	6.6/8.5	50	32
AP60P20K	TO-252	Single	P	-20	±12	0.3/0.65/1.0		5.8/7	60	42
AP50P03K	TO-252	Single	P	-30	±20	1-3	16/20	27/35	35	-
AP70P03K	TO-252	Single	P	-30	±20	0.8-2	7/10	10/13	70	-
AP90P03K	TO-252	Single	P	-30	±20	1.0-2.4	5.6/7.5	8.6/12	90	-
AP9565K	TO-252	Single	P	-40	±20	1-3	25/42.5	35/60	24.5	15.8
AP40P04K	TO-252	Single	P	-40	±20	1-2.5	10/13	15/22	40	26
AP80P04K	TO-252	Single	P	-40	±20	1-2.5	5.8/7	7.5/9	80
AP25P06K	TO-252	Single	P	-60	±20	1-2	49/60	58/72	25	12.7
AP30P06K	TO-252	Single	P	-60	±20	1-2.5	27/32	32/43	30
AP4910GD	PDFN5X6-D	Dual	N+P	-40	±20	1-2.5	13.5/16	16.5/25	40
AP5N20K	TO-252	Single	N	200	±20	1-2.5	430/500	-	5	-
AP5N20K	TO-252	Single	N	200	±20	1-2.5	430/500		5	-
AP20N06T	TO-251	Single	N	60	±20	1-2.5	28/32	34/40	20
AP80N06T	TO-251	Single	N	60	±20	1-2.5	7.5/10	10/14	70
AP120N03	TO-220	Single	N	30	±20	1-2.5	3.1/3.5	4.9/6	120
AP200N04	TO-220	Single	N	40	±20	1.0-2.5	2.3/2.8	3.1/4	160	112
AP3205	TO-220	Single	N	55	±20	2-4	7/8.2	-	110	70
APP50N06	TO-220	Single	N	60	±20	2-4	18/23	-	50
AP50N06	TO-220	Single	N	60	±20	1-3	13/21	20/24	50	-
AP33N10	TO-220	Single	N	100	±20	2-4	33/40		33
AP18N20	TO-220	Single	N	200	±20	2-4	120/150		18
AP200N04D	TO-263	Single	N	40	±20	1.0-2.5	2.3/2.8	3.1/4	160	112
AP30P06	TO-220	Single	P	-60	±20	1-2.5	27/32	32/43	30
AP5N10M	SOT-89	Single	N	100	±20	1-3	115/145	130/160	5
AP12N10S	SOP-8	Single	N	100	20/-12	1-2.5	8/10	11/13.2	12
APG068N04Q	PDFN3X3	Single				1-2.0	5.7/6.8	8.5/11	54
AP20N100Q	PDFN3X3	Single	N	100	20/-12	1-2.5	32/38	49/63	16
APG250N01Q	PDFN3X3	Single	N	100	±20	1-2.5	20/25	30/38	25
APG011N03G	PDFN5X6	Single	N	30	±20	1-2.5	0.9/1.1	1.5/1.7	180
APG068N04G	PDFN5X6	Single	N	40	±20	1-2.0	5.7/6.8	8.5/11	54
APG035N04G	PDFN5X6	Single	N	40	±20	1.2-2.2	2.8/3.2	4.3/5.2	100
APG024N04G	PDFN5X6	Single	N	40	±20	1.2-2.2	2/2.4	2.6/3.2	120
APG4015G	PDFN5X6	Single	N	40	±20	1-2.5	1.6/1.8	2.0/3.3	150
APG013N04G	PDFN5X6	Single	N	40	±20	1-2.5	1.1/1.3	1.6/1.8	160
APG011N04G	PDFN5X6	Single	N	40	±20	1.2-2.2	0.9/1.1	1.3/1.5	200
APG022N06G	PDFN5X6	Single	N	60	±20	1-2.5	1.9/2.3	3.0/3.5	150
APG077N01G	PDFN5X6	Single	N	100	±20	1-2.5	6.4/7.7	8.0/11	90	60
APG095N01G	PDFN5X6	Single	N	100	±20	1.2-2.5	2/9.5	11.3/13	60	38
APG046N01G	PDFN5X6	Single	N	100	±20	1.4-2.4	3.8/4.6	5.2/6.4	85	53
APG038N01G	PDFN5X6	Single	N	100	±20	1.5-2.5	3.1/3.8	4.2/4.9	104	65.7
APG070N12G	PDFN5X6	Single	N	120	±20	1-3	6.0/7.0	7.8/9/4	90
APG080N06GD-AU	PDFN5X6	Dual	N+N	60	±20	1.0-2.5	6.6/8	8.4/10	62	42
APG180N01GD	PDFN5X6-D	Dual	N+N	100	±20	1-2.5	15/18	20/24	25
APG078N07K	TO-252	Single	N	70	±20	2-4	6.7/7.8	-	80
AP7N10K	TO-252	Single	N	100	±20	1-3	100/115	110/130	7
AP40N100K	TO-252	Single	N	100	20/-12	1-2.5	20/25	30/38	40
AP40N100KL	TO-252	Single	N	100	±20	1-2	20/25	30/38	40
AP1310K	TO-252	Single	N	100	±25	1-2.5	14/17	-	50	35
APG095N01K	TO-252	Single	N	100	±20	1.2-2.5	7.8/9.5	10.5/13	60
APG078N07	TO-220	Single	N	70	±20	2-4	6.7/7.8	-	100
APG060N85	TO-220	Single	N	85	±25	2-4	5.5/6		120
APG045N85	TO-220	Single	N	85	±25	2-4	4.2/5		140
AP1310	TO-220	Single	N	100	±25	1-2.5	14/17		50	35
APG082N01	TO-220	Single	N	100	±25	2-4	6.7/8.2		100	70
APG095N01	TO-220	Single	N	100	±20	1.2-2.5	8.2/9.5	11.3/13	80
APG042N01	TO-220	Single	N	100	±20	2-4	3.7/4.2		145
APG060N12	TO-220	Single	N	120	±20	2-4	5.5/6/0		100
APG060N85D	TO-263	Single	N	85	±25	2-4	5.5/6		120	-
APG050N85D	TO-263	Single	N	85	±25	2-4	4.5/5		135	-
APG042N01D	TO-263	Single	N	100	±20	2-4	3.7/4.2		145	-
APG060N12D	TO-263	Single	N	120	±20	2-4	5.5/6	-	100	-
APG080N10	TO-220	Single	N	100	±20	1.2-2.5	6.8/8.0	8.2/10	85	54
APG250N01	TO-220	Single	N	100	±20	1.2-2.8	18/25	25/38	40	25
APG054N10	TO-220	Single	N	100	±20	2-4	4.5/5.4		120	84
APG054N10D	TO-263	Single	N	100	±20	2-4	4.5/5.4		120	84
AP6888	TO-220	Single	N	68	±20	2-4	6.5/8.5		88	54
APG050N85	TO-220	Single	N	85	±25	2-4	4.5/5		135	-

97视频在线免费_殴美成人在线视频_中文字幕一区二区三区不卡_97精品超碰一区二区三区_欧美黄色一区_日韩一级黄色毛片

產(chǎn)品應(yīng)用
